Products >> High Voltage Diodes(5mA ~ 100mA) >> Microwave oven diodes
| Type | Vrrm(KV) | IF(AV)(mA) | IFSM(A) | Tstg(℃) | Vf(V) | Ir1(uA) |
Trr(us)
(If=2mA,IRM=4mA)
|
Outline | |
| CL01-09 | 9 | 350 | 30 | ~40-+120 | 10 | 5 | - | φ7.5*22 φ1.2 | |
| CL01-12 | 12 | 350 | 30 | -40-+120 | 12 | 5 | - | φ7.5*22 φ1.2 | |
| CL01-12A | 12 | 350 | 30 | -40-+120 | 12 | 5 | - | φ7.5*22 φ1.2 | |
| CL04-12 | 12 | 500 | 30 | -40-+120 | 12 | 5 | φ7.5*22 φ1.2 | ||
| CL04-12A | 12 | 500 | 30 | -40-+120 | 12 | 5 | - | φ7.5*22 φ1.2 | |
| CL08-08 | 8 | 350 | 15 | -40-+120 | 14 | 5 | 0.15 | φ7.5*22 φ1.2 | |
Total: 3
Page: 1 / 1
